1 to 36 of 78 items

Page 1 | 2 | 3 | > | >>

Stock Code: 64991032-100

NetiX UTP CAT5E Solid Core Copper 500m Network Cable- Easy Pull Drum Colour Grey-Copper Cable Perfect For Long Distance Cabling, Easy Pull Drum , No Warranty

Click Here For More Detail

Click Here For a Quick Description

NetiX UTP CAT5E Solid Core Copper 500m Network Cable- Easy Pull Drum Colour Grey-Copper Cable Perfect For Long Distance Cabling, Easy Pull Drum , No Warranty

Product Overview
The NetiX UTP CAT5E Solid Core Pure Copper 500m Network Cable is designed for high end and long distance networking cabling installations at for Gigabit-speed connectivity. This cable has a length of 500 metres and it features 24 AWG solid bare copper conductors and a PVC jacket that offers data transmission speeds that exceed Cat 5e standards to provide optimal performance on Gigabit Ethernet networks.

Specifications
• Stock Code 64991032-100
• Description NetiX UTP CAT5E Solid Core Copper 500m Network Cable
• Product Type UTP CAT5E Solid Core Pure Copper Network cable
• Improves Overall Ethernet Performance
• Pure Copper Conductor with 24 AWG Wire Gauge
• Ethernet Support up to 1 Gbps
• 500 Metres in Easy Pull Drum
• Ideal for Long Distance Cabling

Stock Code: TR-58703

Securnix Pure Copper Siamese Coax RG59 and Power Cable 500m Wooden Drum-Black, Retail box, No Warranty

Click Here For More Detail

Click Here For a Quick Description

Securnix Pure Copper Siamese Coax RG59 and Power Cable 500m Wooden Drum-Black, Retail box, No Warranty

Product Overview
The Securnix Siamese Pure Copper Coax RG59 + Power Cable is the professional's choice for CCTV systems that provides both video and power by combining the RG-59 Coax with the 18/2 power, for a single cable pull. The RG59 Siamese constructions save time and money as it allows installers to run both the video and power to security cameras using a single cable run. It's suitable for basic analogue TV antenna feeds in residential applications and for CCTV systems. This Pure copper Siamese cable is convenient because it has both power and video cable wrapped in a single jacket so you don't have to run two separate cables. The Easy Spool roll of Siamese cable won't tangle or snag as you pull your cable out. The RG59 video cable will accept any twist-on BNC connectors or any other standard and compression BNC connectors .
Cable can be cut to exact length

Features
• True RG59 Pure Copper Cable
• 18/2 Siamese Cable,
• One 22AWG (gauge) Bare Copper Coaxial Cable,
• Two 18AWG (gauge) Stranded Power Cables,
• Siamese PVC Jacket.

Cable Specifications
• Stock Code TR-58703
• Description Securnix Siamese Pure Copper Coax cable RG59 + Power Cable 500m Wooden Drum Black
• Cable Type: Siamese Cable
• Power Cable: 18 AWG
• Video Cable: True RG59
• Package Type: Cable Spool
• Runs both video and power in one cable
• Video run in RG59 Coax cable
• Power run through 18 gauge pair
• Works with twist-on, crimp-on,
• Heavily shielded to minimize interference
• Cable Length 500 metres on Drum
• Cable Colour: Black

Stock Code: 12VDC25A18P

Securnix 12VDC 25Amp 18 Channel CCTV Power Supply Box Retail Box

Click Here For More Detail

Click Here For a Quick Description

Securnix 12VDC 25Amp 18 Channel CCTV Power Supply Box Retail Box

Features
• 12 Volts DC
• 25 Amp total output
• Max output current up to 1.85 Amp/Channel
• 18 individually PTC auto-reset fuses protected outputs with LED indicator

Specifications
• Model Number-12VDC25A18P
• Input-85-132VAC or 176-264VAC
• Output-12V DC 25Amp
• Channels-1 in 18 Out CCTV Power Distribution Box (18 channels)

Power Supply
• Switch mode power supply (regulated voltage)
• Max Amp1.85 Amp/Channel

Protection
• Over voltage, over current, and short-circuit protections and Surge Protection

Housing
• Dependable and long lasting,
• Beige metal housing

Dimensions
• Metal Case Size: 37.7(L)*33.2(W)*8.2(D)cm
• Weight Net weight: 3.9kg

Stock Code: KDUT8002

Netix UTP CAT5E Solid Core Copper 305m Network Cable- Easy Pull Box Colour Grey-Copper Cable Perfect For Long Distance Cabling, Brown Box, No Warranty

Click Here For More Detail

Click Here For a Quick Description

Netix UTP CAT5E Solid Core Copper 305m Network Cable- Easy Pull Box Colour Grey-Copper Cable Perfect For Long Distance Cabling, Brown Box, No Warranty

Features
• 305 metres Cat5E Copper cable with Sequential Foot Marking
• Connector Free - perfect for customization.
• Cable rated at 24 AWG and is copper cable
• Spool Box included to provide easy deployment of cable.
• Meet or exceed the industry standard for Category 5e.
• High transmission performance, applied in a bandwidth of over 100 MHz
• Support 1000BASE-T Ethernet (IEEE802.3ab).

Specifications
• Stock Code KDUT8002
• Description Netix UTP CAT5E Solid Core 24AWG Copper Cable 305 metres
• Frequency :1-100MHZ.
• Impedance: 100 ± 15 OHM.
• Structure: PE insulation.
• Shield: Unshielded.
• Flammability grade: CMX, CM, CMG, CMR, CMP.
• Reference standard: ISO / IEC 11801 ANS/TIA/EIA-568A.
• Cable type: Single-core twisted pair.
• Conductor material: Copper

This Copper Cable is perfect for long distance cabling

Stock Code: RG59MIL-300

Securnix Siamese Coax cable RG59 + Power Cable 300m Wooden Brum Standard Spec-Black, Retail box, No Warranty

Click Here For More Detail

Click Here For a Quick Description

Securnix Siamese Coax cable RG59 + Power Cable 300m Wooden Brum Standrd Spec-Black, Retail box, No Warranty.

Product Overview
The Securnix RG-59 Siamese Coax cable is the professional's choice for CCTV systems.
The RG-59 Siamese Coax provides both video and power by combining the RG-59 Coax with the 18/2 power, for a single cable pull.
The RG59 Siamese constructions save time and money as it allows installers to run both the video and power to security cameras using a single cable run
It's suitable for basic analogue TV antenna feeds in residential applications and for CCTV systems.
Siamese cable is convenient because it has both power and video cable wrapped in a single jacket so you don't have to run two separate cables.
The Easy Spool roll of Siamese cable won't tangle or snag as you pull your cable out.
The RG59 video cable will accept any twist-on BNC connectors or any other standard and compression BNC connectors .
Cable can be cut to exact length

Features
True RG59
18/2 Siamese Cable,
One 22AWG (gauge) Bare Copper Coaxial Cable,
Two 18AWG (gauge) Stranded Power Cables,
Siamese PVC Jacket.

Cable Specifications
Cable Type: Siamese Cable
Power Cable: 18 AWG
Video Cable: True RG59
Package Type: Cable Spool
Cable Color: Black
Runs both video and power in one cable
Video run in RG59 Coax cable
Power run through 18 gauge pair
Works with twist-on, crimp-on,
Heavily shielded to minimize interference

Stock Code: CS-W2D-EUP

Ezviz Battery Station for C3A Wireless Battery Camera, Supports access up to 6 FHD resoluton wire-free cameras, Prolong the overall batery life of the cameras by utlizing the extra low power consumpton standby mode,Extend the coverage for wire-free Cameras, 100 decibel siren on the base staton can be triggered when PIR moton is detected,Wired connecton to router., Retail Box, 1 Year Warranty

Click Here For More Detail

Click Here For a Quick Description

Product Overview
Home security is more important than ever, so extend your camera network with this hub from EZVIZ. It allows you to connect up to 6 cameras to a single smart system, letting you monitor every inch of your home and manage it all from any compatible device. And if you spot something suspicious while you’re out and about, you can set off the 100db siren remotely to startle whatever is lurking by your bins – probably just the neighbour’s friendly cat. Plus, for a little extra peace of mind, it extends the battery life of your cameras too, so you won’t need to worry about recharging them quite as often.

Highlights
• Smart hub connects multiple cameras
• Control from a smartphone with the mobile app
• Connects via Ethernet to router for strong connection
• Supports up to 6 cameras to monitor your entire home
• Set off the siren remotely from your smartphone

Stock Code: RG59300M

Securnix Siamese Coax cable RG59 + Power Cable 300m Wooden Drum Military Spec-Black

Click Here For More Detail

Click Here For a Quick Description

Securnix Siamese Coax cable RG59 + Power Cable 300m Wooden Drum Military Spec-Black

Product Overview
The Securnix RG-59 Siamese Coax cable is the professional's choice for CCTV systems.The RG-59 Siamese Coax provides both video and power by combining the RG-59 Coax with the 18/2 power, for a single cable pull. The RG59 Siamese constructions save time and money as it allows installers to run both the video and power to security cameras using a single cable run so you don't have to run two separate cables.

Highlights
• It's suitable for basic analogue TV antenna feeds in residential applications and for CCTV systems.
• Siamese cable is convenient because it has both power and video cable wrapped in a single jacket
• The Easy Spool roll of Siamese cable won't tangle or snag as you pull your cable out.
• The RG59 video cable will accept any twist-on BNC connectors or any other standard and compression BNC connectors .
• Cable can be cut to exact length

Features
• Military Spec Grade True RG59
• 18/2 Siamese Cable,
• One 22AWG (gauge) Bare Copper Coaxial Cable,
• Two 18AWG (gauge) Stranded Power Cables,
• Siamese PVC Jacket.

Cable Specifications
• Cable Type: Siamese Cable
• Power Cable: 18 AWG
• Video Cable: True RG59
• Package Type: Cable Spool
• Cable Colour: Black
• Runs both video and power in one cable
• Video run in RG59 Coax cable
• Power run through 18 gauge pair
• Works with twist-on, crimp-on,
• Heavily shielded to minimize interference

Stock Code: KDUT8004

Netix UTP CAT 6 Copper Clad Aluminium 23AWG Cable -305m Easy Pull Box-Light Grey-Please Note-This is a CCA cable, Retail Box, No Warranty

Click Here For More Detail

Click Here For a Quick Description

Netix UTP CAT 6 Copper Clad Aluminium 23AWG Cable -305m Easy Pull Box-Light Grey-Please Note-This is a CCA cable, Retail Box, No Warranty

The Netix UTP CAT 6 Copper Clad Aluminium 23AWG bulk Cable is used mainly as a standard for cost-effective network cabling solutions . Each twisted pair is made from copper coated aluminium with higher DC resistance than standard copper cable , this cable backward compatible with the Category 5/5e and Category 3 cable standards.

The cable can provide performance of up to 250 MHz and is suitable for 10BASE-T, 100BASE-TX (Fast Ethernet), 1000BASE-T / 1000BASE-TX (Gigabit Ethernet) and 10GBASE-T (10-Gigabit Ethernet) as it is CCA(Copper Clad Aluminium) It comes in a convenient EasyPull™ snag-free dispensing box,

The cable is a fully compliant with international standards ,such as ISO/IEC 11801,ANSI/TIA/EIA-568B.2-1, EN50173, Whether you are wiring your home, office , entire schools or campus the UniQue CAT6 is the right solution.

Stock Code: KDUT8001-CCA

Netix UTP CAT5E CCA Solid Core 24AWG Cable 305m- Easy Pull Box Colour Grey-CCA cable, Brown Box, No Warranty

Click Here For More Detail

Click Here For a Quick Description

Netix UTP CAT5E Solid 24AWG Cable CCA Cable-305m Easy Pull Box-Light Grey-Please Note-This CCA cable for short distance cabling., Retail Box, No Warranty

Features
• 305 metres Solid Core Cat5E CCA cable with Sequential Foot Marking
• Connector Free - perfect for customization.
• Cable rated at 24 AWG and is CCA (Copper Clad Aluminum)
• Spool Box included to provide easy deployment of cable.
• Meet or exceed the industry standard for Category 5e.
• High transmission performance, applied in a bandwidth of over 100 MHz
• Support 1000BASE-T Ethernet (IEEE802.3ab).

Specifications
• Stock Code KDUT8001-CCA

• Description Netix UTP CAT5E CCA Solid Core 24AWG Cable 305 metres
• Frequency :1-100MHZ.
• Impedance: 100 ± 15 OHM.
• Structure: PE insulation.
• Shield: Unshielded.
• Flammability grade: CMX, CM, CMG, CMR, CMP.
• Reference standard: ISO / IEC 11801 ANS/TIA/EIA-568A.
• Cable type: Single-core twisted pair.
• Conductor material: copper clad aluminum

This CCA cable for short distance cabling

Stock Code: CAT5ESOLID-305

Netix UTP CAT5E CCA Solid Core 24AWG Cable 305m- Easy Pull Box Colour Grey-CCA cable, Brown Box, No Warranty

Click Here For More Detail

Click Here For a Quick Description

Netix UTP CAT5E CCA Solid Core 24AWG Cable 305m- Easy Pull Box Colour Grey-CCA cable, Brown Box, No Warranty

Features
• 305 metres Cat5e CCA cable with Sequential Foot Marking
• Connector Free - perfect for customization.
• Cable rated at 24 AWG and is CCA (Copper Clad Aluminum)
• Spool Box included to provide easy deployment of cable.
• Meet or exceed the industry standard for Category 5e.
• High transmission performance, applied in a bandwidth of over 100 MHz
• Support 1000BASE-T Ethernet (IEEE802.3ab).

Specifications
• Stock Code CAT5ESOLID-305
• Description Netix UTP CAT5E CCA Solid Core 24AWG Cable 305 metres
• Frequency :1-100MHZ.
• Impedance: 100 ± 15 OHM.
• Structure: PE insulation.
• Shield: Unshielded.
• Flammability grade: CMX, CM, CMG, CMR, CMP.
• Reference standard: ISO / IEC 11801 ANS/TIA/EIA-568A.
• Cable type: Single-core twisted pair.
• Conductor material: copper clad aluminum

This CCA cable for short distance cabling

Stock Code: POW032

Securnix 12VDC 10Amp 9 Channel CCTV Power Supply Input:110-220VAC, output: 12VDC 10A/9ch, Max ccurrent: 1.6A/ch, PTC 1m AC cord with SA plug, Retail Box, 1 Year Warranty

Click Here For More Detail

Click Here For a Quick Description

Securnix 12VDC 10Amp 9 Channel CCTV Power Supply Input:110-220VAC, output: 12VDC 10A/9ch, Max ccurrent: 1.6A/ch, PTC 1m AC cord with SA plug, Retail Box, 1 Year Warranty

Product Overview

Mutiple outputs power supply 9 channels. The power supply adaptor is stabilized and allows to connect up to 9 devices.
Power supply panel for up to 9 cameras offer a more professional alternative to individual power adapters. Each outlet is individually fused and each panel is surge protected.

Specifications

• Stock Code:POW032
• Description:Securnix 12VDC 10Amp 9 Channel CCTV Power Supply
• Power up to 9 CCTV surveillance cameras
• 12 Volts DC
• 10 Amp total output
• Max output current up to 1.6 Amp/Channel
• 9 individually PTC auto-reset fuses protected outputs with LED indicator Specifications
• Model Number-12DC10A9P
• Input-85-132VAC or 176-264VAC
• Output-12V DC 10Amp
• Channels-1 in 9 Out CCTV Power Distribution Box (9 channels)
• Power Supply-Switch mode power supply (regulated voltage) Protection
• Over voltage, over current, and short-circuit protections and Surge Protection
• Individual PTC Reset-able Fuses Output Protection LED-
• Individual LED power indication
• Internal On/off safety power switch with LED indicator

Housing • Dependable and long lasting • Beige metal housing Dimensions
• Metal Case Size: 24.5(L)*20.6(W)*8.8(D)cm
• Weight Net weight: 1,98kg

Stock Code: GP100

Securnix Video Ground Loop Isolator, BNC male to terminal block with 15cm mini coax cable., ,

Click Here For More Detail

Click Here For a Quick Description

Securnix Video Ground Loop Isolator, BNC male to terminal block with 15cm mini coax cable

Twisted Pair Video Ground Loop Isolator GP100

Product Overview
The Securnix Twisted Pair Video Ground Loop Isolator GP100 are passive devices which reduce Ground Loop Interference with CCTV signals and can easily install in a new or added to existing systems. It is useful where a video signal is transmitted via cable between points with different ground potentials. Differences in ground potentials are typically caused by unbalanced power line loads.

Features:
• BNC male to terminal block with 15cm mini coax cable
• Passive type, no power need
• Hi Performance to eliminate ground loop problem
• Low video loss, Bandwidth: 20hz -11Mhz ,+0/-3Db
• Prevents video-signal distortion caused by video ground loops
• Eliminates picture tearing, cross talk and rolling
• Prevents power cables laid by others interfering with the CCTV system

Specifications:
• Insertion Loss:0.5dB
• Frequency Response:20HZ- 10Mhz,+0/-3dB
• Input Resistance:75 ohm
• Output Resistance:100 ohm
• Isolation Voltage:600VDC (Min)
• Insulation Resistance:100M Ohm
• Transient Voltage Suppressor:12 Vrms
• Material ABS Black
• Dimensions (mm)-72x28x22
• Weight: 156g/pair

Installation View

The Video Ground Loop Isolator should be installed where runs of video cable are known to have ground loops. It must be installed in the video cable that has come directly from the camera, but before the cable has been connected to anything else.

If several video cameras come from the same area, fix a Video Ground Loop Isolator In every cable, or a ground loop will still remain

Stock Code: 550802

Intellinet Wall Mount Bracket - Accessory for Network Dome Cameras 550406, 550420, 550413 and 550444 Aluminum Bracket for wall installation Includes mounting material, Retail Box, Lifetime Warranty

Click Here For More Detail

Click Here For a Quick Description

INT WALL MOUNT BRACKET Accessory for Network Dome Cameras 550406, 550420, 550413 and 550444 Aluminum bracket for wall installation Includes mounting material Retail Box Lifetime Warranty

Product Overview

Intellinet wall mounted bracket for fixed network dome cameras

Color: Silver

Features

Accessory for Network Dome Cameras 550406, 550420, 550413 and 550444

Aluminum bracket for wall installation

Includes mounting material

Specifications

Material: aluminum
Dimensions: 165 (D) x 200 (L) x 100 (W) mm (6.5 x 7.8 x 3.9 in.)

Package Contents
Wall Mount Bracket
Mounting hardware

Stock Code: CAB001-100M-POWAX

Securnix Siamese Copper Coated Aluminium Coax cable RG59 and Power Cable 100m-Black, Retail box, No Warranty

Click Here For More Detail

Click Here For a Quick Description

Securnix Siamese Copper Coated Aluminium Coax cable RG59 and Power Cable 100m-Black, Retail box, No Warranty

Product Overview
The Securnix Siamese Copper Coated Aluminium Coax RG59 and Power Cable 100 metre length is the budget choice for CCTV systems that provides both video and power by combining the RG-59 Coax with the 18/2 power, for a single cable pull. The RG59 Siamese constructions save time and money as it allows installers to run both the video and power to security cameras using a single cable run. It's suitable for basic analogue TV antenna feeds in residential applications and for CCTV systems.

This Copper Coated Aluminium Siamese cable is convenient because it has both power and video cable wrapped in a single jacket so you don't have to run two separate cables. The Easy Spool roll of Siamese cable won't tangle or snag as you pull your cable out. The RG59 video cable will accept any twist-on BNC connectors or any other standard and compression BNC connectors .Cable can be cut to exact length

Features
• RG59 Copper Coated Aluminium Cable 100 metre length
• 18/2 Siamese Cable,
• One 22AWG (gauge) Bare Copper Coaxial Cable,
• Two 18AWG (gauge) Stranded Power Cables,
• Siamese PVC Jacket.

Cable Specifications
• Stock Code CAB001-100M-POWAX
• Description Securnix Siamese Copper Coated Aluminium Coax cable RG59 + Power Cable 100m Black
• Cable Type: Siamese Cable
• Power Cable: 18 AWG
• Video Cable: RG59
• Package Type: Cable Spool
• Runs both video and power in one cable
• Video run in RG59 Coax cable
• Power run through 18 gauge pair
• Works with twist-on, crimp-on,
• Heavily shielded to minimize interference
• Cable Length 100 metre
• Cable Colour: Black

Stock Code: 524407

Intellinet 1/3" CS MOUNT 2.8mm - 12mm Vari-Focal Lens F1.4 - Field of View: 92 - 24 deg Max apeture ratio: 1:1.4 Manual zoom, focus, iris, Retail Box, 1 Year warranty

Click Here For More Detail

Click Here For a Quick Description

Intellinet 1/3" CS MOUNT 2.8mm - 12mm VARI-FOCAL LENS F1.4 Field of View: 92 - 24 deg Max apeture ratio: 1:1.4 Manual zoom, focus, iris Retail Box 1 Year warranty

Features

Compatible with CCTV and network cameras supporting 1/3" CS mount lenses

Field of view: 92° - 24° (wide-angle to telephoto)

Manual zoom, focus & iris control

2.8 - 12.0 mm variable focal length

F 1.4

Compatible with all INTELLINET NETWORK SOLUTIONS Pro-Series cameras, except for IR Night Vision models 550291, 550314, 550307 and 550321

Not suitable for Megapixel cameras

General

Mount: CS, 1/3"

Focal lengths: 2.8 mm - 12.0 mm

Angle of view: 92°- 24°

Max. aperture ratio: 1:1.4

Max. image format: 4.8 mm x 3.6 mm (ø6 mm）

Operating range:
- Focus: 0.5 m - inf.
- Zoom: 2.8 mm - 12.0 mm

Control:
- Iris: manual
- Focus: manual
- Zoom: manual

Environmental

Dimensions: 44 (W) x 84 (L) mm (1.7 x 3.3 in.)

Weight: 128 g (4.5 oz.)

Operating temperature: -10 – 50°C (14 – 122°F)

Package Contents

CCTV Zoom Lens

Lens cover

Stock Code: AE100

Securnix CCTV Video Anti-jamming Device by Coaxial Cable -Active Video Balun

Click Here For More Detail

Click Here For a Quick Description

Securnix CCTV Video Anti-jamming Device by Coaxial Cable -Active Video Balun

Anti-jamming Active Video Balun , Anti-jamming Device AE100

Product Overview
The Securnix CCTV Video Anti-jamming Device by Coaxial Cable -Active Video Balun applies to elevators, hospitals, an intersections, factories etc., avoiding any interference to the process of monitoring the image from any kind of furious electromagnetic signal and electric waves signal.

When you using this kind of product, you can restrain the interference effectively and you can solve the problems about the jiggle, the swirl, the ripple with the images. It is used to ensure the stability of the signals' transmitting quality in bad environment, and to increase the distance of the images transmitting.

Features:
• Transmitter running voltage is rated at DC12 V, receiver don’t need working power, it will work normally if right connect the wire

• Video receiving end of the four stalls brightness adjustment switch is used to adjust image brightness, contrast and definition, adjusting style contain 4x4=16 kinds of combinations

• This product factory brightness adjustment parameters of a switch in the No. 2 stall position; you also can enjoy the scene actual situation of self-correction)

Specifications:
• Transmitter Power in-DC12V ±10%
• Transmitter Power out-DC12V ±10% 0.5A
• Signal standards-NTSC/PAL/CCIR
• Images in-75 ohms 1.0V p-p
• Images out-75 ohms 1.0V p-p
• Images bandwidth-10MHz
• Working environment--10℃ to +45℃
• Storage Temperature--30℃ to +70℃
• Consuming power-<10W
• External dimension-64*25*104mm
• Weight-280g/set

Application Diagram:

Stock Code: VB302T

Securnix single Channel Active Video/Audio/data Transmitter, Aluminum alloy case , , 1 Year Warranty

Click Here For More Detail

Click Here For a Quick Description

Securnix Single Channel Active Video/Audio/data Transmitter, Aluminum alloy case , , 1 Year Warranty

Product Overview
The Securnix VB302T active UTP Video Transmitter converts the unbalanced signal into balanced signal and transmits the signal after pre-raise. Receiver receives balanced signal to convert it into unbalanced signal and restores the received signal with one channel of audio transmission function and two channels of data (or standby interface) with perfect receiving effect, which can be applied in the occasions such as Video Monitoring and video meeting, simplify the wiring project and save wire use quantity.

Features:
• Adopt differential signal transmission with excellent anti-jamming ability
• Save project wire expenses, each a pair of twisted pair wire transmits one channel of video signal and one common Cat-5 unshielded twisted pair wire can simultaneously transmit four channels of video signal
• The farthest transmission distance can reach 2400m if it is used with active receiver
• Outstanding interference rejection, transient protection
• Aluminium Alloy Case

Specifications:
• Video Format NTSC, PAL, and SECAM
• Frequency Response DC to 8MHz
• Attenuation 0.5dB typical
• CMRR 60 dB
• Impedance Coax, Male BNC 75 ohms
• RJ45/Terminal Block 100 ohms
• Working environment Working Temperature -10℃ to +70℃
• Storage Temperature -30℃ to +70℃
• Humidity   0 to 95%
• Wire Type UTP5
• Connector Female BNC, RJ45 and terminal Block
• Power 12VDC (Max:90mA)
• Case Aluminium alloy case
• Dimension 105mm*70mm*29mm
• Weight   185g/pc

Type of the required wire:
• Unshielded Cat-5 or above twisted pair wire
(Please use standard Cat-5 or above twisted pair wire. The wire quality will directly affect the transmitted image effect and transmission distance.)
• Characteristic impedance:100Ω±20Ω
• DC Loop Resistance: 18Ω/100m
• Differential capacitance: 62pf/m (maximum)

Stock Code: GB100

Securnix Video Ground Loop Isolator, BNC male to BNC female with 25cm mini coax cable on both side., ,

Click Here For More Detail

Click Here For a Quick Description

Securnix Video Ground Loop Isolator, BNC male to BNC female with 25cm mini coax cable on both side

Passive Video Ground Loop Isolator for CCTV with 25CM Cable, Video Ground Loop Isolator, GB100

Product Overview
The Securnix Passive Video Ground Loop Isolator for CCTV with 25CM Cable, Video Ground Loop Isolator, GB100 are passive devices which reduce Ground Loop Interference with CCTV signals and can easily install in a new or added to existing systems. It is useful where a video signal is transmitted via cable between points with different ground potentials. Differences in ground potentials are typically caused by unbalanced power line loads.

Features:
• BNC male to BNC female with mini cable 25 on both sides
• Passive, no power required
• Prevents video-signal distortion caused by video ground loops
• Eliminates picture tearing, cross talk and rolling
• Prevents power cables laid by others interfering with the CCTV system
• Built in TVS (Transient Voltage Suppressors) for surge protection
• Built in Video filter, perfect to work with DVR to immunity DVR interference, for extra interference rejection
• Others same as Ground Loop Isolator function

Specifications:
• Insertion Loss 0.5dB
• Frequency Response 20HZ- 10Mhz,+0/-3dB
• Input Resistance 75 ohm
• Output Resistance 75 ohm
• Isolation Voltage 600VDC (Min)
• Insulation Resistance 100M Ohm
• Transient Voltage Suppressor 12 Vrms
• Material ABS Black
• Dimensions (mm) 72*28*21 with 25cm*2 cable
• Weight: 100g/pc

Installation View
The Video Ground Loop Isolator should be installed where runs of video cable are known to have ground loops. It must be installed in the video cable that has come directly from the camera, but before the cable has been connected to anything else. If several video cameras come from the same area, fix a Video Ground Loop Isolator In every cable, or a ground loop will still remain.

Stock Code: VB120T

Securnix Single Channel Active Video Balun, , 1 Year Warranty

Click Here For More Detail

Click Here For a Quick Description

Securnix Single Channel Active Video Balun, , 1 Year Warranty

75 Ohm to 100 Ohm Active Video Balun for CCTV , Rj45 Video Balun, VB120T

Product Overview
The Securnix VB120T 75 Ohm to 100 Ohm Active Video Balun for CCTV , Rj45 Video Balun, active UTP video transmitter is to convert the video signal into the balanced signal applicable to be transmitted on common Cat-5 unshielded twisted pair wire with perfect transmission effect, which can be applied in the occasions such as video monitoring and video meeting and can transmit four channels of video image simultaneously on an 8-core Cat-5 twisted pair wire. It can simplify the wiring project and save wire use quantity.

Specifications:
• Video Format-NTSC, PAL, and SECAM
• Frequency Response-DC to 6MHz
• Attenuation-0.5dB typical
• CMRR-60 dB
• Wire Type-UTP5
• Connector-Female BNC and Terminal Block
• Power-12VDC
• Case-Aluminium alloy case

Impedance
• Coax, Male BNC 75 ohms
• RJ45/Terminal Block 100 ohms

Working environment
• Working Temperature -10℃ to +70℃
• Storage Temperature -30℃ to +70℃
• Humidity 0 to 95%

Dimension-82mm*79mm*29mm
Weight-107g/pc

Type of the required wire:
• Unshielded Cat-5 or above twisted pair wire
(Please use standard Cat-5 or above twisted pair wire. The wire quality will directly affect the transmitted image effect and transmission distance.)
• Characteristic impedance:100Ω±20Ω
• DC loop resistance: 18Ω/100m
• Differential capacitance: 62pf/m (maximum)

Connection method:
• Connect the two-colour wires of a pair of Cat-5 unshielded twisted pair wire to the ‘+’ terminal of the yellow socket and connect the single-color wires to the ‘-’ terminal of the green socket.
• Connect the BNC interface of the transmitter to the BNC interface of the camera. If there is any joint in the circuit, please adopt welding method or special junction box to ensure perfect contact at the joint.

Adjusting method:
• Adjust and slide the switch according to the distance

1 to 36 of 78 items

Page 1 | 2 | 3 | > | >>

Photographed products shown above are for illustrative purposes only. www.esquireshop.com © 2021
