Stock Code: PRIME_Z790-P_D4

Asus PRIME Z790-P D4 LGA 1700 Motherboard - Intel Socket LGA1700 for 13th Gen Intel Core Processors & 12th Gen Intel Core, Pentium Gold and Celeron Processors, Intel Z790 Chipset, 4x DDR4 DIMM Memory Slots, 4x SATA6 Connectors, 3x M.2 Key M Connectors, On-Board Display: 1x HDMI Connector, 1x DisplayPort Connector, 1x Intel I219-V 1Gb Ethernet port, On-Board Realtek 7.1 Surround Sound High Definition Audio CODEC, 1x PCIe 5.0 x16 slot, 3x PCIe 4.0 x16 slots (support x4 mode), 1x PCIe 3.0 x1 slot, 1x USB 3.2 Gen 2x2 port (1 x USB Type-C®), 1x USB 3.2 Gen 2 port (1 x Type-A), 2x USB 3.2 Gen 1 ports (2 x Type-A), 4x USB 2.0 ports (4 x Type-A), ATX Form Factor, Retail Box, 1 year warranty

Click Here For More Detail
Click Here For a Quick Description
Asus PRIME Z790-P D4 LGA 1700 Motherboard - Intel Socket LGA1700 for 13th Gen Intel Core Processors & 12th Gen Intel Core, Pentium Gold and Celeron Processors, Intel Z790 Chipset, 4x DDR4 DIMM Memory Slots, 4x SATA6 Connectors, 3x M.2 Key M Connectors, On-Board Display: 1x HDMI Connector, 1x DisplayPort Connector, 1x Intel I219-V 1Gb Ethernet port, On-Board Realtek 7.1 Surround Sound High Definition Audio CODEC, 1x PCIe 5.0 x16 slot, 3x PCIe 4.0 x16 slots (support x4 mode), 1x PCIe 3.0 x1 slot, 1x USB 3.2 Gen 2x2 port (1 x USB Type-C®), 1x USB 3.2 Gen 2 port (1 x Type-A), 2x USB 3.2 Gen 1 ports (2 x Type-A), 4x USB 2.0 ports (4 x Type-A), ATX Form Factor, Retail Box, 1 year warranty

Product Overview
ASUS Prime series motherboards are expertly engineered to unleash the full potential of 13th Gen Intel® Core™ Processors. Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, PRIME Z790-P D4 provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features.

Features
Outstanding Audio
•Combined onboard features deliver elevated audio.Intelligent design and premium hardware create audio quality unlike anything you’ve ever experienced.
Audio Shielding
•Audio shielding ensures precision analog/digital separation and greatly reduced multi-lateral interference.
Dedicated Audio PCB Layers
•Separate layers for left and right tracks ensures both channels deliver consistent, equal quality.

Specifications
•Product code: PRIME_Z790-P_D4
•Description: Asus PRIME Z790-P D4 LGA 1700 Motherboard
•ATX Form Factor
•Intel Z790 Chipset
•Socket LGA 1700
•4x DDR4 DIMM Slots, Supports Up To 128GB
•Supports Up to DDR4-5333MHz (OC)
•Supports Intel XMP Memory Profiles
•1x PCIe 5.0 x16 Slot
•3x PCIe 4.0 x4 Slots
•1x PCIe 3.0 x1 Slot
•2x M.2 22110 PCIe 4.0 x4 NVMe SSD Slots
•1x M.2 2280 PCIe 4.0 x4 NVMe SSD Slot
•4x SATA 3.0 6.0Gbps Ports
•1x USB 3.2 Gen 2x2 20Gbps Type-C Port
•1x USB 3.2 Gen 2 10Gbps Type-A Port
•2x USB 3.2 Gen 1 5Gbps Type-A Ports
•4x USB 2.0 Type-A Ports
•1x HDMI 2.1, 1x DisplayPort 1.4
•3x 3.5mm Audio Jacks (Line Out, Line In, Microphone)
•Realtek 2.5 Gigabit Ethernet RJ-45 LAN






Stock Code: PROH610M-EDDR4

MSI PRO H610M-E DDR4 LGA1700 Motherboard - Support Intel Core 14th, 13th, 12th Gen Processors, Intel Pentium Gold and Celeron Processors, Intel H610 Chipset, 2x DDR4 memory slots, support up to 64GB, 4x SATA 6Gb/s ports, 1x M.2 slots (Key M), 1x HDMI 1.4 with HDR port, supports a maximum resolution of 4K 30Hz, 1x VGA port, 6x USB 2.0 ports (2 Type-A port on the back panel, 4 ports available through internal USB 2.0 connectors), 1x USB 3.2 Gen 2x2 20Gbps Type-C port on the back panel, 2x USB 3.2 Gen 2 1.5Gbps Type-A ports, 4x USB 2.0 Type-A ports on the back panel, 1x PCIe x16 slots, 1x PCIe 3.0 x1 slot, Realtek ALC897 Codec, 1x Realtek RTL8111H 1Gbps LAN controller - m-ATX Form Factor, Retail Box, 3 year warranty

Click Here For More Detail
Click Here For a Quick Description
MSI PRO H610M-E DDR4 LGA1700 Motherboard - Support Intel Core 14th, 13th, 12th Gen Processors, Intel Pentium Gold and Celeron Processors, Intel H610 Chipset, 2x DDR4 memory slots, support up to 64GB, 4x SATA 6Gb/s ports, 1x M.2 slots (Key M), 1x HDMI 1.4 with HDR port, supports a maximum resolution of 4K 30Hz, 1x VGA port, 6x USB 2.0 ports (2 Type-A port on the back panel, 4 ports available through internal USB 2.0 connectors), 1x USB 3.2 Gen 2x2 20Gbps Type-C port on the back panel, 2x USB 3.2 Gen 2 1.5Gbps Type-A ports, 4x USB 2.0 Type-A ports on the back panel, 1x PCIe x16 slots, 1x PCIe 3.0 x1 slot, Realtek ALC897 Codec, 1x Realtek RTL8111H 1Gbps LAN controller - m-ATX Form Factor, Retail Box, 3 year warranty

Product Overview
MSI PRO series motherboards help users work smarter by delivering an efficient and productive experience. Featuring stable functionality and high-quality assembly, PRO series motherboards provide not only optimized professional workflows but also less troubleshooting and longevity.

Features
•Supports 12th Gen Intel® Core™, Pentium® Gold and Celeron® processors for LGA 1700 socket
•Supports DDR4 Memory, up to 3200(MAX) MHz
•Core Boost: With premium layout and digital power design to support more cores and provide better performance
•Memory Boost: Advanced technology to deliver pure data signals for the best performance, stability and compatibility
•Lightning Fast Experience: PCIe 4.0
•Audio Boost: Reward your ears with studio grade sound quality
•Steel Armor: Protecting VGA cards against bending and EMI for better performance, stability and strength.

Specifications
•Product code: PROH610M-EDDR4
•Description: MSI PRO H610M-E DDR4 LGA1700 Motherboard
•Socket: 1700
•Chipset: Intel® H610 Chipset
•DDR4 Memory: 3200(MAX) / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz
•Memory Channel: Dual Channel
•DIMM Slots: 2
•Max Memory (GB): 64
•PCI-E x16: 1
•PCI-E x1: 1
•SATAIII: 4
•M.2 Slot: 1
•TPM (Header): 1
•LAN: 1x Realtek® RTL8111H Gigabit LAN controller
•USB 3.2 ports (Front): 2(Gen 1, Type A)
•USB 3.2 ports (Rear): 2(Gen 1, Type A)
•USB 2.0 ports (Front): 4
•USB 2.0 ports (Rear): 4
•Audio ports (Rear): Realtek® ALC897 Codec
•VGA: 1
•HDMI: 1
•DirectX: 12
•Form Factor: mATX
