ASUS ROG STRIX B550-A GAMING. Processor manufacturer: AMD, Compatible processor series: AMD Ryzen 3. Supported memory types: DDR4-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storage drive interfaces: PCI Express 3.0. Motherboard form factor: ATX, Motherboard chipset family: AMD, Motherboard chipset: AMD B550. BIOS type: UEFI, BIOS memory size: 256 Mbit.

Product Overview

The ASUS ROG Strix B550-A Gaming AM4 ATX Motherboard is designed for AMD Ryzen processors, offering robust performance and compatibility. It supports DDR4 memory up to 128GB, PCIe 3.0 interfaces, and features an advanced UEFI BIOS for seamless configuration. With its sleek ATX form factor and AMD B550 chipset, it’s ideal for gaming and high-performance builds.

Features

•PCIe 4.0 Support: Includes dual M.2 slots, with one supporting PCIe 4.0 for fast storage and performance flexibility.
•Powerful Performance: Robust 12+2 power stages, advanced cooling, and support for high-speed memory ensure reliable gaming and multitasking.
•Connectivity: Equipped with WiFi 6E, Intel 2.5 Gb Ethernet, USB 3.2 Gen 2, HDMI 2.1, and DisplayPort for seamless networking and device compatibility.
•Customizable Design: Features Aura Sync RGB lighting and cyberpunk-inspired aesthetics for a personalized gaming setup.
•User-Friendly: Includes DIY-friendly features like pre-mounted I/O shield, BIOS FlashBack™, and intuitive software for easy configuration.

Specifications

•Product Code: ROG-STRIX-B550-A-GAMING
•Description: ASUS ROG Strix B550-A Gaming WiFi II Motherboard
•CPU Support: AMD Ryzen Series Desktop Processors
•Chipset: B550
Memory:
•4 x DIMM slots, Max. 128GB
DDR4 support:
•Ryzen 5000/3000: Up to 4800(O.C.) / 4666(O.C.) / 4600(O.C.) / down to 2133 MHz
•Ryzen 4000 G-Series: Up to 5100(O.C.) / down to 2133 MHz
Graphics:
•1 x DisplayPort 1.2
•1 x HDMI 2.1
Expansion Slots:
•1 x PCIe 4.0 x16 Slot (supports x16 mode)
•1 x PCIe 3.0 x16 slot (supports x4 mode)
•3 x PCIe 3.0 x1 slots
Storage Supports:
•2 x M.2 slots (PCIe & SATA modes)
•6 x SATA 6Gb/s ports (RAID support for RAID 0, 1, and 10)
Ethernet:
•Intel I225-V 2.5Gb Ethernet with ASUS LANGuard
•Wireless & Bluetooth:
•Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
•Bluetooth v5.2
USB Ports:
•Rear: Total of 8 ports (including USB Type-C)
•2 x USB 3.2 Gen 2 ports
•4 x USB 3.2 Gen 1 ports
•2 x USB 2.0 ports
Audio:
•ROG SupremeFX S1220A codec, supports up to 7.1 channel audio
Back Panel I/O Ports:
•Includes USB ports, Wi-Fi module, DisplayPort, HDMI, Ethernet, optical S/PDIF out, and audio jacks.
•Form Factor: ATX (30.5cm x 24.4cm)
•Operating System Support: Windows 11 and Windows 10 (64-bit)

Asus Prime A520M-K Motherboard CPU: Socket: LGA1200 Processor Support: 10th and 11th Gen Intel Core, Pentium Gold, and Celeron processors Technology: Intel Turbo Boost Technology 2.0 Chipset: Intel H510 Form Factor: Micro ATX Memory: Slots: 2 x DIMM Memory Support: DDR4 Max Capacity: 64GB Architecture: Dual-channel Memory Speed: DDR4 4600(O.C)/4400(O.C)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200 /3000/2800/2666/2400/2133 MHz Un-buffered Memory Graphics: Ports: 1 x D-Sub, 1 x HDMI 2.0 Resolution: HDMI 2.0 (4K@60Hz) Expansion Slots: 1 x PCIe 3.0 x16 2 x PCIe 3.0 x1 Storage: 4 x SATA 6Gb/s ports 1 x M.2 slot (Key M) Ethernet: 1 x Realtek 1Gb Ethernet USB (Rear): Total 6 ports 4 x USB 3.2 Gen 1 ports (Type-A) 2 x USB 2.0 ports (Type-A) USB (Internal): 2 x USB 3.2 Gen 1 port(s) (Type-A) 4 x USB 2.0 port(s) (Type-A) Internal I/O Ports: 1 x CPU Fan connector(s) 1 x Chassis Fan connector(s) 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode) 1 x SPI TPM header 4 x SATA 6Gb/s connector(s) 1 x S/PDIF out header(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin EATX 12V Power connectors 1 x Front panel audio connector(s) (AAFP) 1 x Clear CMOS jumper(s) 1 x System panel connector 1 x COM port header 1 x Speaker connector

Product Overview

The ASUS Prime A520M-K Motherboard is designed for 10th and 11th Gen Intel processors, featuring an LGA1200 socket and Intel H510 chipset for optimal performance. It supports dual-channel DDR4 memory up to 64GB with speeds reaching 4600 MHz (overclocked), ensuring fast and efficient data handling. With multiple connectivity options, including HDMI 2.0 for 4K resolution and M.2 slots for high-speed storage, this micro ATX motherboard is perfect for both everyday users and DIY PC builders.

Specifications

•Product Code: 90MB1500-M0EAY0
•Description: ASUS PRIME A520M-K AMD AM4 M/ATX BOARD
•Processor manufacturer: AMD
•Compatible processor series: 10th and 11th Gen Intel Core, Pentium Gold, and Celeron processors Technology
•Supported memory types: DDR4-SDRAM
•Memory slots type: DIMM
•Supported memory clock speeds: DDR4 4600(O.C)/4400(O.C)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200 /3000/2800/2666/2400/2133 MHz
•Supported storage drive interfaces: M.2, Serial ATA
•LAN controller: Realtek RTL8111H
•Motherboard form factor: micro ATX
•Motherboard chipset: AMD A520M-k

The MSI A520M-A PRO motherboard supports 3rd Gen AMD Ryzen Desktop Processors and AMD Ryzen 4000 G-Series processors, utilizing the AMD A520 chipset. It features dual-channel DDR4 memory support up to 64GB with speeds reaching 4600 MHz in OC mode, along with a PCIe x16 slot for graphics expansion and four SATA III ports for storage.

Product Overview

The MSI A520M-A PRO motherboard is designed to deliver reliable performance and stability, supporting 3rd Gen AMD Ryzen processors and up to 64GB of DDR4 RAM. It features a robust set of connectivity options, including Gigabit LAN via Realtek RTL8111H, multiple USB ports, HDMI, and DVI-D outputs for versatile display configurations. With its micro-ATX form factor and extensive compatibility with popular memory brands, this motherboard offers flexibility and high-quality audio through Realtek codecs for enhanced user experience

Features

•Support 3rd Gen AMD Ryzen Desktop Processors and AMD Ryzen 4000 G-Series Desktop Processors
•Supports DDR4 Memory, up to 4600(OC) MHz
•Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs
•Core Boost: With premium layout and digital power design to support more cores and provide better performance
•DDR4 Boost: Advanced technology to deliver pure data signals for the best performance and stability
•2oz Thickened Copper PCB: An enhanced PCB design improves heat dissipation and performance reliability
•Audio Boost: Reward your ears with studio grade sound quality
•Dragon Center: A brand new software which integrates all MSI exclusive tools with user friendly user interface

Specifications

•Product Code: A520M-APRO
•Description: MSI A520M-A PRO AMD Gaming Motherboard
•Socket: AMD Socket AM4
•CPU (Max Support): Support 3rd Gen AMD Ryzen Desktop Processors and AMD Ryzen 4000 G-Series Desktop Processors
•Chipset: AMD® A520 Chipset
•DDR4 Memory: Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC – Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+ MHz by A-XMP OC Mode
•Memory Channel: Dual
•DIMM Slots: 2
•Max Memory (GB): 64
•PCI-E x16: 1
•PCI-E GEN: Gen3
•PCI-E x1: 1
•SATAIII: 4
•M.2 Slot: 1
•TPM (Header): 1
•RAID: 0/1/10
•LAN: 1x Realtek® RTL8111H Gigabit LAN
•USB 3.2 ports (Front): 2(Gen 1, Type A)
•USB 3.2 ports (Rear): 4(Gen 1, Type A)
•USB 2.0 ports (Front): 4
•USB 2.0 ports (Rear): 2(Type A)
•Serial Ports(Front): 1
•Audio ports (Rear): Realtek® ALC892/ALC897 Codec
•DVI-D: 1
•HDMI: 1
•DirectX: 12
•Form Factor: M-ATX
•Operating System: Support for Windows® 10 64-bit

The MSI A520M PRO motherboard is designed to support a wide range of AMD Ryzen processors, including the 5000 and 4000 series, utilizing the AMD Socket AM4 and A520 chipset for reliable performance. It features dual-channel DDR4 memory support of up to 4600MHz (OC), multiple expansion slots, and various display interfaces, including HDMI and DisplayPort, ensuring versatility for any build. With robust connectivity options, including USB 3.2 ports and Realtek Gigabit LAN, this motherboard is ideal for both gaming and professional applications.

Product Overview

MSI PRO Series motherboards are expertly crafted to enhance professional workflows, offering stable functionality and high-quality assembly for optimized performance. With features like Intel LAN for reliable connectivity, extensive memory testing, and superior audio quality, they cater to demanding users who require efficiency and reliability. Ideal for professionals and tech enthusiasts alike, these motherboards provide the tools needed to fine-tune systems for maximum performance.

Features

•Supports AMD Ryzen 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series and 3000 G-Series processors
•Supports DDR4 Memory, up to 4600(OC) MHz
•Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs
•Core Boost: With premium layout and digital power design to support more cores and provide better performance.
•DDR4 Boost: Advanced technology to deliver pure data signals for the best performance and stability.
•2oz Thickened Copper PCB: An enhanced PCB design improves heat dissipation and performance reliability.
•Audio Boost: Reward your ears with studio-grade sound quality

Specifications

•Product Code: A520M-PRO
•Description: MSI A520M-PRO AMD AM4 MATX Gaming Motherboard
•Socket: AMD Socket AM4
•CPU (Max Support): Supports AMD Ryzen 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series and 3000 G-Series process
•Chipset: AMD A520 Chipset
•DDR4 Memory: Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC - Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+ MHz by A-XMP OC Mode
•Memory Channel: Dual
•DIMM Slots: 2
•Max Memory (GB): 64
•PCI-E x16: 1
•PCI-E GEN: Gen3
•PCI-E x1: 2
•SATAIII: 4
•M.2 Slot: 1
•TPM (Header): 1
•RAID: 0/1/10
•LAN: Realtek RTL8111H Gigabit LAN
•USB 3.2 ports (Front): 2(Gen 1, Type A)
•USB 3.2 ports (Rear): 4(Gen 1, Type A)
•USB 2.0 ports (Front): 4
•USB 2.0 ports (Rear): 2(Type A)
•Serial Ports(Front): 1
•Audio ports (Rear): Realtek ALC892/ALC897 Codec
•DisplayPort: 1
•HDMI: 1
•VGA: 1
•DirectX: 12
•Form Factor: M-ATX
•Operating System: Support for Windows 10 & Windows 11
