Stock Code: SOLUPLIBC

Solarix Ultra Power 48V 20A Lithium Ion Phosphate Battery Charger -4 Steps Charging, Maximum Charging Output Voltage(CV) 54.8V, Maximum Output Current (CC): 20 Amps, AC Input Voltage 220VAC, AC Input Frequency 50 Hz, Input Power1000W (1380W Maximum), Lightweight Aluminium Casing With Ventilation Fan, 2x Round 8.2mm Output Connector Lugs, Colour Black, Retail Box, 1 Year Limited Warranty

Click Here For More Detail
Click Here For a Quick Description
Solarix Ultra Power 48V 20A Lithium Ion Phosphate Battery Charger -4 Steps Charging, Maximum Charging Output Voltage(CV) 54.8V, Maximum Output Current (CC): 20 Amps, AC Input Voltage 220VAC, AC Input Frequency 50 Hz, Input Power1000W (1380W Maximum), Lightweight Aluminium Casing With Ventilation Fan, 2x Round 8.2mm Output Connector Lugs, Colour Black, Retail Box, 1 Year Limited Warranty

Product Overview

The Solarix Ultra Power 48V 20 A Lithium Ion Phosphate Battery Charger is designed to optimise the performance and lifespan of Lithium Ion Phosphate (Lifepo4) batteries and can safely achieve a 100% State of Charge. This 48V 20 A battery charger operates from mains AC 220-240V as input, supplying up to 20A charging output suitable for nominal 48V LiFePO4 battery banks. The charger's built-in protection technology provides protection against Over Voltage and Over Current output, Short Circuit making it very safe to use. With energy efficiency > 85%, the charger produces less heat, delivers more energy and allows faster charging in less than 2 hours . The Lightweight Aluminium Casing is equipped with active ventilation fan system that allows the charger to be used in harsh environments or hot climates



Highlights
• Ultra Power Lithium Ion Phosphate Battery Charger
• 4 Steps Charging
• Maximum Charging Output Voltage(CV) 54.8V
• Maximum Constant Output Current (CC): 20 Amps
• AC Input Voltage 220VAC Max 240VAC
• AC Input Frequency 50 Hz
• Power Efficiency >85% At Full Load
• Output Power1000W (1380W Maximum Output)
• Lightweight Aluminium Casing With Ventilation Fan
• 2x Round 8.2mm Output Connector Lugs

Specifications
• Stock Code SOLUPLIBC
• Description Solarix Ultra Power Lithium Ion Phosphate Battery Charger
• Product Type 4 Steps Charging System
• Input Voltage Min 220VAC to Max 240VAC
• Output Power1000W (1380W Maximum Output)
• Constant Charge Voltage Min 58.1VDC to Max 58.7VDC
• Constant Current 20A
• Charge Complete Current VDC Min 1.2A to Max 1.8A
• Power Efficiency >85% At Full Load
• Colour Black
• Dimensions Length 210mm x W-125mm x H-70mm
• Weight 3.0Kg

Stock Code: SOLUPLIBC24V

Solarix Ultra Power 24V 20A Lithium Ion Phosphate Battery Charger-4 Steps Charging, Maximum Charging Output Voltage (CV) 29.2V, Maximum Output Current (CC): 20 Amps, AC Input Voltage 220VAC, AC Input Frequency 50 Hz, Input Power 600W Maximum, Lightweight Aluminium Casing With Ventilation Fan, 2x Round 8.2mm Output Connector Lugs, Colour Black, Retail Box, 1 Year Limited Warranty

Click Here For More Detail
Click Here For a Quick Description
Solarix Ultra Power 24V 20A Lithium Ion Phosphate Battery Charger-4 Steps Charging, Maximum Charging Output Voltage (CV) 29.2V, Maximum Output Current (CC): 20 Amps, AC Input Voltage 220VAC, AC Input Frequency 50 Hz, Input Power 600W Maximum, Lightweight Aluminium Casing With Ventilation Fan, 2x Round 8.2mm Output Connector Lugs, Colour Black, Retail Box, 1 Year Limited Warranty

Product Overview
The Solarix Ultra Power 24V 20 A Lithium Ion Phosphate Battery Charger is designed to optimise the performance and lifespan of Lithium Ion Phosphate (Lifepo4) batteries and can safely achieve a 100% State of Charge. This 24V 20 A battery charger operates from mains AC 220-240V as input, supplying up to 20A charging output suitable for nominal 24V LiFePO4 battery banks. The charger's built-in protection technology provides protection against Over Voltage and Over Current output, Short Circuit making it very safe to use. With energy efficiency > 85%, the charger produces less heat, delivers more energy and allows faster charging around 2 hours .The Lightweight Aluminium Casing is equipped with active ventilation fan system that allows the charger to be used in harsh environments or hot climates


Highlights
•Ultra Power Lithium Ion Phosphate Battery Charger
•4 Steps Charging
•Maximum Charging Output Voltage(CV) 29.2V
•Maximum Constant Output Current (CC): 20 Amps
•AC Input Voltage 220VAC Max 240VAC
•AC Input Frequency 50 Hz
•Power Efficiency >85% At Full Load
•Output Power 600W Maximum Output
•Lightweight Aluminium Casing With Ventilation Fan
•2x Round 8.2mm Output Connector Lugs

Specifications
•Stock Code SOLUPLIBC
•Description Solarix Ultra Power Lithium Ion Phosphate Battery Charger
•Product Type 4 Steps Charging System
•Input Voltage Min 220VAC to Max 240VAC
•Output Power 600W Maximum Output
•Constant Charge Voltage Max 29.2VDC
•Constant Current 20A
•Charge Complete Current VDC Min 1.2A to Max 1.8A
•Power Efficiency >85% At Full Load
•Colour Black
•Dimensions Length 150mm x W-80mm x H-70mm
•Weight 2.0Kg


Stock Code: SOLTAICOBEL48V

Solarix 48V Battery Equaliser And Balance Charger - Can Be Connected To 48V Battery Banks (4x 12V In Series), Monitors Each Battery Voltage, No External Power Supply Is Required, Retail Box, 1 Year Limited Warranty

Click Here For More Detail
Click Here For a Quick Description
Solarix 48V Battery Equaliser And Balance Charger - Can Be Connected To 48V Battery Banks (4x 12V In Series), Monitors Each Battery Voltage, No External Power Supply Is Required, Retail Box, 1 Year Limited Warranty

Product Overview
The Solarix 48V Battery Equaliser And Balance Charger is used for range of batteries such as Lead-acid , AGM and Lithium batteries which are connected in series to keep battery voltage balanced. On deviation of more than 24 mV, the higher voltage battery will be discharged to the lower voltage batteries until all the battery voltages are equal. This will improve battery's performance and extent battery's life time. No external power supply is required.

The Solarix 48V Battery Equaliser And Balance Charger  supports up to 4 × 12V batteries connection by default. No matter whether the bank is connected in series or parallel. Multiple 48V Battery Equalizers can be installed in parallel to equalize 60V, 72V, and 96V battery banks. One equalizer can connect four batteries at a time. The extra cable can be emptied if the battery is less than 4 (positive and negative terminals should be avoided). It won’t affect the equalization effects.



We highly recommend using a voltmeter when working with this product

Specifications
• Stock Code SOLTAICOBEL48V
• Description Solarix 48v Battery Equaliser And Balance Charger
• Battery Banks Of 4 x 12v In Series Can Be Used
• Monitors Each Battery Voltage
• Keeps Batteries In Optimal Condition
• Up To 10amp Inter Battery Balancing
• Reverse Polarity Protection
• Ensures Longer Service Life Of Batteries
• Required For 4x 12v Batteries To Be Connected In Series
• Multiple 48V Battery Equalizers installed in parallel to equalize 60V, 72V, and 96V battery banks.
• Easily Connects To Batteries With Included Wiring
• No External Power Supply Is Required
• Optimization Current-Controlled Between 0 To 10A
• Quiescent Current: 5mA(12V) 1.2mA(2.4V)
• Under Voltage Lockout: 1.8V
• Compatible With Lead-Acid , AGM And Lithium Iron Phosphate Batteries
• Dimensions: 62×124×27 mm
• Weight 0.5kg

What's in the box
• 1x Battery Balancer with built-in connectors
• 1x Manual

Stock Code: SOLTAICOBEL24V

Solarix 24V Battery Equaliser And Balance Charger - Can Be Connected To 24V Battery Banks (2x 12V In Series), Monitors Each Battery Voltage, No External Power Supply Is Required, Retail Box, 1 Year Limited Warranty

Click Here For More Detail
Click Here For a Quick Description
Solarix 24V Battery Equaliser And Balance Charger - Can Be Connected To 24V Battery Banks (2x 12V In Series), Monitors Each Battery Voltage, No External Power Supply Is Required, Retail Box, 1 Year Limited Warranty

Product Overview
The Solarix 24V Battery Equaliser And Balance Charger is used for range of batteries such as Lead-acid , AGM and Lithium batteries which are connected in series to keep battery voltage balanced. On deviation of more than 20 mV, the higher voltage battery will be discharged to the lower voltage batteries until all the battery voltages are equal. This will improve battery's performance and extent battery's life time. No external power supply is required

The Solarix 24V Battery Equaliser And Balance Charger is designed to be used to balance 24V battery banks comprised of multiple 12V batteries. It is a plug and play device that does not need any adjustment. Simply connect the 3x ring terminals to the respective connections on the batteries. The two display screens simply show the voltage of the battery that the cables are connected to.


For a 24V system, 1x unit is required
For a 36V system, 2x units are required
For a 48V system, 3x units are required

Multiple can be installed in parallel to increase balancing current. Simply stack the 8mm ring terminals on top of each other.

The left screen shows the voltage across the 0V-12V (red and white cables) and the right screen shows the voltage between the 12V-24V (white and black cables).

We highly recommend using a voltmeter:

-Red cable - 24V
-White cable - 12V
-Black cable - 0V

Specifications

• Stock Code SOLTAICOBEL24V
• Description Solarix 24v Battery Equaliser And Balance Charger
• Battery Banks Of 2x 12v In Series Can Be Used
• Monitors Each Battery Voltage
• Keeps Batteries In Optimal Condition
• Up To 10amp Inter Battery Balancing
• Reverse Polarity Protection
• Ensures Longer Service Life Of Batteries
• Required For 2x 12v Batteries To Be Connected In Series
• Easily Connects To Batteries With Included Wiring
• No External Power Supply Is Required
• Optimization Current-Controlled Between 0 To 5 A
• Low Power Consumption Of 3ma
• Compatible With Lead-Acid , AGM And Lithium Iron Phosphate Batteries
