Stock Code: DVR-116G-M1

HiLook 16CH Hybrid DVR High Definition Stand Alone DVR - Support H.265 Pro+/H.265 Pro/H.265 video compression, Advanced Motion Detection Ver2 Deep learning based human and vehicle targets classification, 16 Channel Analog and HD-TVI video input, BNC interface (1.0Vp-p, 75 Ω),supporting coaxitron connection, Audio Input: 1-ch RCA and 16-ch via coaxial cable, SATA Interface Support up to 10TB Hard disk drive, 10/100 self-adaptive Ethernet interface 2x USB 2.0 Ports on Rear panel, Supports real-time 1080p lite when enabled the image effect is similar to 1080p, HDMI/VGA output at up to 1920 × 1080 resolution, IP 2ch Up to 18-ch IP camera input (up to 5 MP), Signal Input HDTVI/AHD/CVI/CVBS/IP, 1U Mini White Unit, Smart search for efficient playback, Remote viewing from anywhere on pc and cellphone, Retail Box , 1 year warranty

Click Here For More Detail

Click Here For a Quick Description

Product Overview

Experience advanced surveillance capabilities with the HiLook 16CH Hybrid DVR, offering high-definition video compression and deep learning-based motion detection for precise human and vehicle target classification. With support for multiple video inputs, up to 10TB HDD storage, and remote viewing from any device, it ensures comprehensive security monitoring with ease.

Specifications

•Product code: DVR-116G-M1

•Description: HiLook 16CH Hybrid DVR High Definition Stand Alone DVR

•Human/Vehicle Analysis

•H.265 Pro+/H.265 Pro/H.265/H.264+/H.264

•For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF

•For 720p stream access: 720p/WD1/4CIF/VGA/CIF

•For SD stream access: WD1/4CIF/VGA/CIF

•For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF@15 fps

•For 720p stream access: 720p/WD1/4CIF/VGA/CIF@15 fps

•For SD stream access: WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)

•For 1080p and 720p stream access CIF/QVGA@15 fps

•Dual-Stream

•Support

•Stream Type

•Video, Video & Audio

•Audio Compression

•G.711u

•Audio Bitrate

•64 Kbps

•Video And Audio

•IP Video Input

•2-ch (up to 18-ch)

•Up to 5 MP resolution

•AHD Input

•1080p25, 1080p30, 720p25, 720p30

•HDCVI Input

•1080p25, 1080p30, 720p25, 720p30

•1-ch RCA (2.0 Vp-p, 1 KΩ)

•1-ch, RCA (Linear, 1 KΩ)

•≤ 7 W (without HDD)

•Working Temperature

•-10 °C to 55 °C (14 °F to 131 °F)

•Dimension (W × D × H)

•285 × 210 × 45 mm (11.2 × 8.3 × 1.8 inch)

•≤ 1.8 kg (without HDD, 4.0 lb.)

Stock Code: DS-7108HGHI-F1

Hikvision 7100 Series 8CH Turbo High Definition Stand Alone DVR - Support H.264+/H.264 video compression, 8 Channel Analog and HD-TVI video input, BNC interface (1.0Vp-p, 75 Ω),supporting coaxitron connection, Audio Input: 1-ch RCA, SATA Interface Support up to 6TB Hard disk drive, 10/100 self-adaptive Ethernet interface 2x USB 2.0 Ports on Rear panel, Supports real-time 1080p lite when enabled the image effect is similar to 1080p, HDMI/VGA output at up to 1920 × 1080 resolution, IP 2ch Up to 10-ch IP camera input (up to 4 MP), Signal Input HDTVI/AHD/CVI/CVBS/IP, Motion 1.0, 1U Mini White Unit, Smart search for efficient playback, Remote viewing from anywhere on pc and cellphone, Retail Box , 1 year warranty

Click Here For More Detail

Click Here For a Quick Description

Hikvision 7108 Series 8CH Turbo High Definition Stand Alone DVR - Support H.264+/H.264 video compression, 8 Channel Analog and HD-TVI video input, BNC interface (1.0Vp-p, 75 Ω),supporting coaxitron connection, Audio Input: 1 channel, SATA Interface Support up to 6TB Hard disk drive, 10/100 self-adaptive Ethernet interface 2x USB 2.0 Ports on Rear panel, Supports real-time 1080p lite when enabled, the image effect is similar to 1080p, HDMI/VGA output at up to 1920 × 1080 resolution, Retail Box , 1 year warranty

Product Overview:
Turbo HD DVR is an advanced recorder developed by Hikvision independently which can connect HD analog cameras and provide powerful surveillance. It features multiple advanced technologies, such as audio and video encoding & decoding technology, embedded system technology, storage technology, network technology and intelligent technology. It can both work alone as a recorder and cooperate with other devices to build a comprehensive surveillance system. This DVR is widely applied in the areas of finance, public security, military, communication, transportation, education, etc.

Features:

• Support H.264+/H.264 video compression
• Support HDTVI/AHD/CVI/CVBS/IP video input
• Up to 4-ch 960p IP camera input for DS-7104HGHI-F1, up to 8/16-ch 1080p IP camera input for DS-7108/7116HGHI-F1
• Max. 1200 m for 720p HDTVI signal

Please Note : The Cameras and Hard Disk Drive up to 6TB are not included in this package , They can be purchased separately

Specifications:
• Product Code: DS-7108HGHI-F1
• Description: Hikvision 7108 Series 8CH Turbo High Definition Stand Alone DVR

• Hikvision 7108 Series 8CH Turbo High Definition Stand Alone DVR

• Support H.264+/H.264 video compression

• 8 Channel Analog and HD-TVI video input

• BNC interface (1.0Vp-p, 75 Ω) supporting coaxitron connection

• Audio Input: 1 channel

• SATA Interface Support up to 6TB Hard disk drive

• 10/100 self-adaptive Ethernet interface 2x USB 2.0 Ports on Rear panel

• Supports real-time 1080p lite when enabled the image effect is similar to 1080p

• HDMI/VGA output at up to 1920 × 1080 resolution

• Retail Box

• 1 year warranty

Stock Code: DVR-108G-M1

HILOOK DVR (XVR) 8CH AOC 2MP LITE

Click Here For More Detail

Click Here For a Quick Description

HiLook 8CH Hybrid DVR High Definition Stand Alone DVR - Support H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 video compression, 8 Channel Analog and HD-TVI video input, BNC interface (1.0Vp-p, 75 Ω),supporting coaxitron connection, Audio Input: 1-ch RCA and 8-ch via coaxial cable Audio via coaxial cable, SATA Interface Support up to 4TB Hard disk drive, 10/100 self-adaptive Ethernet interface 2x USB 2.0 Ports on Rear panel, Supports real-time 1080p lite when enabled the image effect is similar to 1080p, HDMI/VGA output at up to 1920 × 1080 resolution, IP 2ch Up to 10-ch IP camera input (up to 5 MP), Signal Input HDTVI/AHD/CVI/CVBS/IP, Deep learning based human and vehicle targets classification of Motion Detection 2.0, 1U Mini White Unit, Smart search for efficient playback, Remote viewing from anywhere on pc and cellphone, Retail Box , 1 year warranty

Product Overview

HiLook 8CH Hybrid DVR High Definition Stand Alone DVR

Features

•H.265 Pro+/H.265 Pro/H.265 video compression

•HDTVI/AHD/CVI/CVBS/IP video input

•Up to 10-ch IP camera input (up to 5 MP)

Specifications

•Product code: DVR-108G-M1

•Description: HiLook 8CH Hybrid DVR High Definition Stand Alone DVR

•Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264

•Encoding Resolution: For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF

•For 720p stream access: 720p/WD1/4CIF/VGA/CIF

•For SD stream access: WD1/4CIF/VGA/CIF

•Main stream:For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF@15 fps

•For 720p stream access: 720p/WD1/4CIF/VGA/CIF@15 fps

•For SD stream access: WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)

•For 1080p and 720p stream access CIF/QVGA@15 fps

•For SD stream access: CIF/QVGA@25 fps (P)/30 fps (N)

•Support H.265+/H.265/H.264+/H.264 IP cameras

•BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection

•HDTVI Input:1080p25, 1080p30, 720p25, 720p30

•AHD Input: 1080p25, 1080p30, 720p25, 720p30

•HDCVI Input: 1080p25, 1080p30, 720p25, 720p30

•HDMI Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz

•VGA Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz

•Video Output Mode: HDMI/VGA simultaneous output

•Audio Input: 1-ch RCA (2.0 Vp-p, 1 KΩ)

•Audio Output: 1-ch, RCA (Linear, 1 KΩ)

•TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP™, HTTPS

•1, RJ45 10/100 Mbps self-adaptive Ethernet interface

•Power Supply: 12 VDC, 1.5 A

•200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch)

•≤ 1 kg (without HDD, 2.2 lb.)
